Home » Products » Angular Contact Ball Bearings » Chrome Steel 3200 3201 3202 3203 3204 Bearing /Angular Contact Ball Bearing

Chrome Steel 3200 3201 3202 3203 3204 Bearing /Angular Contact Ball Bearing

Similar to other ball bearings, angular contact ball bearings are composed of inner and outer races, ball complement and bearing cage; however, different to other ball bearings like a deep groove ball bearing, an angular contact ball bearing is designed with axially asymmetric race.
Availability:
Quantity:
sharethis sharing button

Why Choose Us:
1.With more than 25 years experiences of producing and R&D bearings.
2. All of ours roller bearing and ball bearings with CE ISO TUV certificate
3. Our products have been exported to about thirty country/areas, and enjoyed a high reputation on the domestic and overseas market.
4. The OEM and ODM are available.
5. Professional after-sales team
6. Offering most reasonable price

147316475714731546961473156335

Automotive Bearings:

Automotive Bearings
Engine
System
Generator Deep Groove Ball Bearing, Cylindrical Roller Bearing
Pulley Angular Contact Ball Bearing
Tensioning Wheel Deep Groove Ball Bearing, Tapered Roller Bearing, Pillow Block Bearing
Water Pump Angular Contact Ball Bearing, Cylindrical Roller Bearing
Drive
System
Clutch Release Angular Contact Ball Bearing, Thrust Ball Bearing
Transmission Ball Bearing, Tapered Roller Bearing, Cylindrical Roller Bearing
Shaft Support Thrust Needle Bearing
Final Reducer and Differential Tapered Roller Bearing, Cylindrical roller bearing
Wheel Hub Angular Contact Ball Bearing, Deep Groove Ball Bearing, Tapered Roller Bearing
Steering System Steering Column Needle Bearing
Steering Shaft Needle Bearing
Steering Gear Cylindrical Roller Bearing, Thrust Ball Bearing
Knuckle Kingpin Cylindrical Roller Bearing, Tapered Roller Bearing
Air conditioner System Air condition Compressor Angular Contact Ball Bearing
Electromagnetic Clutch Angular Contact Ball Bearing

About Angular Contact Ball Bearing:

Similar to other ball bearings,  angular contact ball bearings are composed of inner and outer races, ball complement and bearing cage; however, different to other ball bearings like a deep groove ball bearing, an angular contact ball bearing is designed with axially asymmetric race.

595256 (2)595256 (6)595256 (4)595256 (1)

We also supply & produce:

Ball Bearing Deep Groove Ball Bearing

60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **,

160 **(70001 )

Thrust Ball Bearing

511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series

Angular Contact Ball bearing

SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series

Roller Bearing Spherical Roller bearing

239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on

Taper Roller Bearing

329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings such as 938/932 single and double row i.e M255410CD etc.

Thrust Roller Bearing

292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series.

Cylindrical Roller Bearing

NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in steel Industry.

Mod. No. d D Height Cr Cor Grease Oil Weight
(mm) (mm) (mm) (kN) (kN) (r/min) (r/min) (kg)
7010C 50 80 16 26 21.9 13000 17000 0.29
7010AC 50 80 16 23.6 20.1 9200 11000 0.29
7210C 50 90 20 42.8 31.8 12000 16000 0.485
7210AC 50 90 20 39.4 41.3 8500 11000 0.485
7210B 50 90 20 37.535.7 26.7 6400 8500 0.485
7310B 50 110 27 64.4 44.3 5500 7300 1.14
7410B 50 130 31 90.2 60.4 4400 6000 1.92
7011C 55 90 18 34.1 28.6 11000 15000 0.42
7011AC 55 90 18 31.1 26.3 8300 10000 0.42
7211C 55 100 21 52.9 40.2 11000 14000 0.635
7211AC 55 100 21 48.7 37.1 7600 9500 0.635
7211B 55 100 21 44.1 33.8 5700 7600 0.635
7311B 55 120 29 74.3 52 5000 6700 1.45
7012C 60 95 18 35 30.6 11000 14000 0.45
7012AC 60 95 18 31.9 28.1 7700 9700 0.45
7212C 60 110 22 64 49.5 9500 13000 0.82
7212AC 60 110 22 58.9 45.7 6900 8600 0.82
7212B 60 110 22 53.4 41.6 5100 6900 0.82
7312B 60 130 31 84.9 60.3 4600 6200 1.81
7412B 60 150 35 119 86.7 3700 5100 2.85
7013C 65 100 18 37.1 34.3 10000 13000 0.47
7013AC 65 100 18 33.7 31.4 7200 9000 0.47
7213C 65 120 23 73.1 58.7 8900 12000 1.02
7213AC 65 120 23 67.3 54.2 6400 8000 1.02
7213B 65 120 23 60.9 49.3 4800 6400 1.02
7313B 65 140 33 96.1 69.3 4300 5800 2.22
7014C 70 110 20 46.9 43 9200 12000 0.66
7014AC 70 110 20 42.7 39.4 6600 8300 0.66
7214C 70 125 24 75.9 60.2 8400 11000 1.12
7214AC 70 125 24 69.8 55.6 6100 7600 1.12
7214B 70 125 24 63.2 50.6 4600 6100 1.12
7314B 70 150 35 108 78.9 4000 5400 2.7
7015C 75 115 20 48 45.6 8700 11000 0.69
7015AC 75 115 20 43.6 41.7 6300 7800 0.69
7215C 75 130 25 86.1 70.6 8000 11000 1.23
7215AC 75 130 25 79.2 65.2 5800 7200 1.23
7215B 75 130 25 71.7 59.3 4300 5800 1.23
7915B 75 160 37 125 98.5 3400 4500 3.3
7016C 80 125 22 58.7 55.3 8000 11000 0.93
7016AC 80 125 22 53.4 50.6 5800 7200 0.93
7216C 80 140 26 92.8 77.5 7500 9900 1.5
7216AC 80 140 26 85.3 71.5 5400 6700 1.5
7216B 80 140 26 77.1 65 4000 5400 1.5
7316B 80 170 39 127 100 3500 4700 3.85
7017C 85 130 22 60.1 58.7 7600 10000 0.97
7017AC 85 130 22 54.6 53.7 5500 6800 0.97
7217C 85 150 28 107 90.6 7000 9200 1.87
7217AC 85 150 28 98.6 83.6 5000 6300 1.87
7217B 85 150 28 89.2 76 3800 5000 1.87
7317B 85 180 41 137 112 3300 4400 4.53
7018C 90 140 24 71.7 69.1 7100 9400 1.26
7018AC 90 140 24 65.2 63.3 5100 6400 1.26
7218C 90 160 30 123 105 6500 8600 2.3
7218AC 90 160 30 113 96.7 4700 5900 2.3
7218B 90 160 30 102 88 3500 4700 2.3
7318B 90 190 43 148 124 3100 4200 5.3
7019C 95 145 24 73.4 73.4 6700 8900 1.32
7019AC 95 145 24 66.6 67.1 4800 6000 1.32
7219C 95 170 32 133 112 6100 8100 2.78
7219AC 95 170 32 122 103 4400 5500 2.78
7219B 95 170 32 111 94 3300 4400 2.78
7319B 95 200 45 158 137 3000 4000 6.12

Testing:
Roughness-machine
Roughness-machine
Vibration-&-noise-testing
Radial-clearance-check
Id-dial-comparator
Hardness-tester
Axial-Clarence-Machine
Digico-meter
Feeler-gauge
Roughness-and-contour

Packaging & Shipments:
Packaging Details:
 1.tube /plastic bag+box+cartons+pallets
2.plastic bag+single box+cartons+pallets
3.industrial packing+cartons+pallets
Delivery Details:
 Less than 1000PCS, deliver  within 5 days by Express or Airplane.
 More than 1000PCS, deliver within 15 days by sea.

payment delivery

Application:
Typical Applications: electric motors, fork lift trucks, pumps, textile machinery, transmissions, wire guide & spring machinery, medium belt conveyors, wood working machineries, and so on.

Aviation Cargo Systems Industrial Mixers & Shakers
Aerospace Wing Actuators Intrusion Detection Systems
Anemometer Material Handling Rollers
ATMs & Card Readers Medical Actuator
Bicycles Medical Diagnostic Equipment
Commercial Blenders Medical Imaging Equipment
Dental Hand Tools Medical Laser Surgery
Electrical Motors Medical Surgical Tools
Engines Off Highway Cranes
Escalators and Elevators Optical Encoders
Fishing Reels Plastic Card Printers
Flight Support Systems Power Hand Tools
Flow Meters Printing Rollers
Galvanometers Roller Doors
Gas Engine Pull Start Assembly Scissor & Platform Lifts
Gas Meters Sensors & Potentiometers
Gas Powered Motors Solar Panels Actuators

1473156120FAQ:
1. Are you a factory or a trading company?
 Shandong XSY Bearing Co., Ltd. is a professional manufacture of deep groove ball bearings and other bearings.
 2. Is OEM available?
 Yes, OEM is available. We have professional designer to help your brand promotion.
 3. Is the sample available?
 Yes, samples are available for you to test the quality.
 4. Have the products been tested before shipping?
 Yes, all of our bearings have been tested before delivery.
 5. How long is your delivery time?
 As mentioned above, there are different types of shipping for your order. We make sure to deliver goods once all products are produced and tested.
 6. What is your terms of payment ?
 You can pay by T/T, L/C, Westunion, Paypal,etc., and it can be negotiated according to different orders with different amount.
 7. Can we visit your factory ?
 Sure. Welcome to XSY Bearing Co., Ltd. and offer your kind guidance.
8.How to stock and maintenance my bearings?
Do not store bearings directly on concrete floors, where water can condense and collect on the bearing;
Store the bearings on a pallet or shelf, in an area where the bearings will not be subjected to high humidityor extreme temperature that may result in condensation forming;
Always put oiled paper or, if not available, put plastic sheets between rollers and cup races of tapered roller bearings.
