There is an angle between the ligature of steel ball of contact ball bearing and its contact point with inner & outside circles and radical side. The angel is generally 15°,30°,40°, showing with letter C, A, B respectively. Angular contact ball bearings have raceways in the inner and outer rings that are displaced relative to each other in the direction of the bearing axis. This means that they are designed to accommodate combined acting radial and axial loads.
Bearing No. | Boundary dimensions | Mass | ||
mm | kg | |||
d | D | B | ≈ | |
7000AC | 10 | 26 | 8 | 0.019 |
7001AC | 12 | 28 | 8 | 0.021 |
7002AC | 15 | 32 | 9 | 0.03 |
7003AC | 17 | 35 | 10 | 0.04 |
7004AC | 20 | 42 | 12 | 0.064 |
7005AC | 25 | 47 | 12 | 0.074 |
7006AC | 30 | 55 | 13 | 0.11 |
7007AC | 35 | 62 | 14 | 0.15 |
7008AC | 40 | 68 | 15 | 0.18 |
7009AC | 45 | 75 | 16 | 0.23 |
7010AC | 50 | 80 | 16 | 0.25 |
7011AC | 55 | 90 | 18 | 0.38 |
7012AC | 60 | 95 | 18 | 0.4 |
7013AC | 65 | 100 | 18 | 0.43 |
7014AC | 70 | 110 | 20 | 0.6 |
7015AC | 75 | 115 | 20 | 0.63 |
7016AC | 80 | 125 | 22 | 0.85 |
7017AC | 85 | 130 | 22 | 0.89 |
7018AC | 90 | 140 | 24 | 1.15 |
7019AC | 95 | 145 | 24 | 1.2 |
7020AC | 100 | 150 | 24 | 1.25 |
7021AC | 105 | 160 | 26 | 1.6 |
7022AC | 110 | 170 | 28 | 1.95 |
7024AC | 120 | 180 | 28 | 2.1 |
7026AC | 130 | 200 | 33 | 3.33 |
7028AC | 140 | 210 | 33 | 3.46 |
7030AC | 150 | 225 | 35 | 4.8 |
7032AC | 160 | 240 | 38 | 5.26 |
7000C | 10 | 26 | 8 | 0.019 |
7001C | 12 | 28 | 8 | 0.021 |
7002C | 15 | 32 | 9 | 0.03 |
7003C | 17 | 35 | 10 | 0.04 |
7004C | 20 | 42 | 12 | 0.064 |
7005C | 25 | 47 | 12 | 0.074 |
7006C | 30 | 55 | 13 | 0.11 |
7007C | 35 | 62 | 14 | 0.15 |
7008C | 40 | 68 | 15 | 0.18 |
7009C | 45 | 75 | 16 | 0.23 |
7010C | 50 | 80 | 16 | 0.25 |
7011C | 55 | 90 | 18 | 0.38 |
7012C | 60 | 95 | 18 | 0.4 |
7013C | 65 | 100 | 18 | 0.43 |
7014C | 70 | 110 | 20 | 0.6 |
7015C | 75 | 115 | 20 | 0.63 |
7016C | 80 | 125 | 22 | 0.85 |
7017C | 85 | 130 | 22 | 0.89 |
7018C | 90 | 140 | 24 | 1.15 |
7019C | 95 | 145 | 24 | 1.2 |
7020C | 100 | 150 | 24 | 1.25 |
7021C | 105 | 160 | 26 | 1.6 |
7022C | 110 | 170 | 28 | 1.95 |
7024C | 120 | 180 | 28 | 2.1 |
7026C | 130 | 200 | 33 | 3.33 |
7028C | 140 | 210 | 33 | 3.46 |
7030C | 150 | 225 | 35 | 4.8 |
7032C | 160 | 240 | 38 | 5.26 |
There is an angle between the ligature of steel ball of contact ball bearing and its contact point with inner & outside circles and radical side. The angel is generally 15°,30°,40°, showing with letter C, A, B respectively. Angular contact ball bearings have raceways in the inner and outer rings that are displaced relative to each other in the direction of the bearing axis. This means that they are designed to accommodate combined acting radial and axial loads.
Bearing No. | Boundary dimensions | Mass | ||
mm | kg | |||
d | D | B | ≈ | |
7000AC | 10 | 26 | 8 | 0.019 |
7001AC | 12 | 28 | 8 | 0.021 |
7002AC | 15 | 32 | 9 | 0.03 |
7003AC | 17 | 35 | 10 | 0.04 |
7004AC | 20 | 42 | 12 | 0.064 |
7005AC | 25 | 47 | 12 | 0.074 |
7006AC | 30 | 55 | 13 | 0.11 |
7007AC | 35 | 62 | 14 | 0.15 |
7008AC | 40 | 68 | 15 | 0.18 |
7009AC | 45 | 75 | 16 | 0.23 |
7010AC | 50 | 80 | 16 | 0.25 |
7011AC | 55 | 90 | 18 | 0.38 |
7012AC | 60 | 95 | 18 | 0.4 |
7013AC | 65 | 100 | 18 | 0.43 |
7014AC | 70 | 110 | 20 | 0.6 |
7015AC | 75 | 115 | 20 | 0.63 |
7016AC | 80 | 125 | 22 | 0.85 |
7017AC | 85 | 130 | 22 | 0.89 |
7018AC | 90 | 140 | 24 | 1.15 |
7019AC | 95 | 145 | 24 | 1.2 |
7020AC | 100 | 150 | 24 | 1.25 |
7021AC | 105 | 160 | 26 | 1.6 |
7022AC | 110 | 170 | 28 | 1.95 |
7024AC | 120 | 180 | 28 | 2.1 |
7026AC | 130 | 200 | 33 | 3.33 |
7028AC | 140 | 210 | 33 | 3.46 |
7030AC | 150 | 225 | 35 | 4.8 |
7032AC | 160 | 240 | 38 | 5.26 |
7000C | 10 | 26 | 8 | 0.019 |
7001C | 12 | 28 | 8 | 0.021 |
7002C | 15 | 32 | 9 | 0.03 |
7003C | 17 | 35 | 10 | 0.04 |
7004C | 20 | 42 | 12 | 0.064 |
7005C | 25 | 47 | 12 | 0.074 |
7006C | 30 | 55 | 13 | 0.11 |
7007C | 35 | 62 | 14 | 0.15 |
7008C | 40 | 68 | 15 | 0.18 |
7009C | 45 | 75 | 16 | 0.23 |
7010C | 50 | 80 | 16 | 0.25 |
7011C | 55 | 90 | 18 | 0.38 |
7012C | 60 | 95 | 18 | 0.4 |
7013C | 65 | 100 | 18 | 0.43 |
7014C | 70 | 110 | 20 | 0.6 |
7015C | 75 | 115 | 20 | 0.63 |
7016C | 80 | 125 | 22 | 0.85 |
7017C | 85 | 130 | 22 | 0.89 |
7018C | 90 | 140 | 24 | 1.15 |
7019C | 95 | 145 | 24 | 1.2 |
7020C | 100 | 150 | 24 | 1.25 |
7021C | 105 | 160 | 26 | 1.6 |
7022C | 110 | 170 | 28 | 1.95 |
7024C | 120 | 180 | 28 | 2.1 |
7026C | 130 | 200 | 33 | 3.33 |
7028C | 140 | 210 | 33 | 3.46 |
7030C | 150 | 225 | 35 | 4.8 |
7032C | 160 | 240 | 38 | 5.26 |
