QHW15CA QHW20CA QHW20HA QHW25CA QHW25HA QHW30CA QHW30HA QHW35CA QHW35HA QHW45CA QHW45HA
ZGXSY, OEM, WORD FAMOUS BRAND, NO BRAND
China
Bearing Steel, GCR 15
WEH-CA Series
12 Months / One Year
X-Y axes, high-end automation field, high-speed sorting and packaging production lines
By International Express or Sea or Railway
1 PC
CA Series: High-performance standard type. Utilizing high-grade bearing steel and deep precision grinding processes, this series focuses on providing superior accuracy retention, wear resistance, and reliability compared to general-purpose products in conventional industrial environments.
HA Series: Ultra-long life/extreme condition type. Its core technology may involve the use of special alloy materials (such as high-temperature alloys), ceramic balls, or advanced surface treatment technologies (such as composite coatings, ion nitriding, etc.). Designed specifically to handle extremely demanding application environments such as high temperature, high vacuum, highly corrosive media, or lifetime maintenance-free operation.
| Model No. | Diensions of Assembly [mm] | Dimension of Block [mm] | Dimension of Rail [mm] | Mounting Bolt for Rail | Basic Dynamic Load Rating | Basic Static Load Rating | Static Rated Moment | Weight | ||||||||||||||||||||||||
| H | H1 | N | W | B | B1 | C | L1 | L | K1 | K2 | G | M | T | T1 | H2 | H3 | WR | HR | D | h | d | P | E | [mm] | C(kN) | C0(kN) | MR(kN·m) | MP(kN·m) | MY(kN·m) | Block(kg) | Rail(kg/m) | |
| QHW15CA | 24 | 4 | 16 | 47 | 38 | 4.5 | 30 | 39.4 | 61.4 | 8 | 5 | 5.3 | M5 | 6 | 8.9 | 3.95 | 4.2 | 15 | 15 | 7.5 | 5.3 | 4.5 | 60 | 20 | M4x16 | 17.94 | 19.86 | 0.1 | 0.112 | 0.112 | 0.17 | 1.45 |
| QHW20CA | 30 | 4.6 | 21.5 | 63 | 53 | 5 | 40 | 50.5 | 76.7 | 9.75 | 6 | 12 | M6 | 8 | 10 | 6 | 6 | 20 | 17.5 | 9.5 | 8.5 | 6 | 60 | 20 | M5x16 | 30 | 33.86 | 0.26 | 0.266 | 0.266 | 0.4 | 2.21 |
| QHW20HA | 65.2 | 91.4 | 17.1 | 35.7 | 42.31 | 0.31 | 0.37 | 0.37 | 0.52 | |||||||||||||||||||||||
| QHW25CA | 36 | 5.5 | 23.5 | 70 | 57 | 6.5 | 45 | 58 | 83.4 | 10.7 | 6 | 12 | M8 | 8 | 14 | 6 | 5 | 23 | 22 | 11 | 9 | 7 | 60 | 20 | M6x20 | 41.9 | 48.75 | 0.39 | 0.46 | 0.46 | 0.59 | 3.21 |
| QHW25HA | 78.6 | 104 | 21 | 50.61 | 60.94 | 0.5 | 0.576 | 0.576 | 0.8 | |||||||||||||||||||||||
| QHW30CA | 42 | 6 | 31 | 90 | 72 | 9 | 52 | 70 | 97.4 | 13.5 | 6.25 | 12 | M10 | 8.5 | 16 | 6.5 | 6 | 28 | 26 | 14 | 12 | 9 | 80 | 20 | M8x25 | 58.26 | 66.34 | 0.6 | 0.66 | 0.66 | 1.09 | 4.47 |
| QHW30HA | 93 | 120.4 | 25.75 | 70.32 | 88.45 | 0.83 | 1.19 | 1.19 | 1.44 | |||||||||||||||||||||||
| QHW35CA | 48 | 7.5 | 33 | 100 | 82 | 9 | 62 | 80 | 113.6 | 13 | 7.5 | 12 | M10 | 10.1 | 18 | 8.5 | 6.5 | 34 | 29 | 14 | 12 | 9 | 80 | 20 | M8x25 | 78.89 | 86.66 | 1.07 | 1.022 | 1.022 | 1.56 | 6.3 |
| QHW35HA | 105.8 | 139.4 | 25.9 | 95.23 | 115.55 | 1.45 | 1.919 | 1.919 | 2.06 | |||||||||||||||||||||||
| QHW45CA | 60 | 9.2 | 37.5 | 120 | 100 | 10 | 80 | 97 | 139.4 | 13 | 10 | 12.9 | M12 | 15.1 | 22 | 8.5 | 10 | 45 | 38 | 20 | 17 | 14 | 105 | 22.5 | M12x35 | 119.4 | 135.42 | 1.83 | 2.092 | 2.092 | 2.79 | 10.41 |
| QHW45HA | 128.8 | 171.2 | 28.9 | 144.13 | 180.56 | 2.47 | 4.002 | 4.002 | 3.69 | |||||||||||||||||||||||
1. Optimized Load Distribution Groove Design: Utilizing bidirectional large contact angle arc grooves, the ball bearings achieve optimal stress distribution when subjected to loads from various directions, significantly improving fatigue life.
2. Surface Treatment Technology: The guide rail raceways undergo deep carburizing and quenching or high-frequency quenching, followed by ultra-precision constant-temperature grinding, ensuring extremely high hardness and excellent surface finish, resulting in outstanding wear resistance and corrosion resistance.
3. Fully Sealed Protection: Equipped with a three-layer sealing system (end face oil scraper, side metal chip guard, and internal labyrinth seal), it provides IP54 or higher dustproof and waterproof protection, effectively preventing chips, dust, and liquids from entering.
1. High Precision and High Rigidity: The HA series is particularly outstanding, maintaining micron-level motion accuracy even under heavy loads.
2. Exceptional Durability and Lifespan: Optimized materials and heat treatment processes, combined with equal load design, result in a significantly longer rated lifespan (L10) compared to ordinary products.
3. Excellent Running Smoothness: Precision manufacturing ensures extremely low starting force and running friction, resulting in smooth and fluid motion without any sticking.
4. High Environmental Adaptability: Enhanced sealing and anti-corrosion treatment enable it to perform reliably in harsh working conditions such as those found in machine tools and forging equipment.
5. Low Maintenance Costs: Long lifespan and reliable sealing reduce maintenance frequency and downtime.
This series is specifically designed to address the challenges of heavy-duty, high-precision, and long-term continuous operation. Typical applications include:
1. High-end CNC machine tools: Feed axes of machining centers, CNC milling machines, and grinding machines.
2. Precision stamping and forming equipment: Moving tables of precision presses and die-casting machines.
3. Heavy-duty automation systems: Large gantry robots and stacker cranes in automated warehouses.
4. Inspection and measurement equipment: Coordinate measuring machines and large workpiece vision measuring instruments.
5. New energy equipment: Precision motion platforms for lithium battery winding machines and photovoltaic panel laminating machines.
