Product Description:
CGH-CA / HA Series Direct Linear Guide is developed for applications requiring high rigidity within a reduced installation footprint. The series adopts a dense internal guiding structure to deliver strong mechanical support and precise linear motion, making it suitable for equipment where stiffness and space efficiency must be balanced.
Specification:
| Model No. | Dimensions of Assembly (mm) | Dimensions of Block (mm) | Dimensions of Rail (mm) | Mounting Bolt for Rail | Basic Dynamic Load Rating | Basic Static Load Rating | Static Rated Moment (kgf·m) | Weight | |||||||||||||||||||||||
| H | H1 | N | W | B | B1 | C | L | L | G | K1 | K2 | T | H2 | H3 | M x l | WR | HR | D | h | d | P | E | (mm) | C(kN) | C0(kN) | MR kN·m | MP kN·m | My kN·m | Block kg | Rail kg/m | |
| CGH15CA | 28 | 4.1 | 9.5 | 34 | 26 | 4 | 26 | 39.6 | 58.2 | 6 | 10.8 | 4.25 | 6 | 7.8 | 7.8 | M4 x 6 | 15 | 16.2 | 7.5 | 5.9 | 4.5 | 60 | 20 | M4x17 | 14.7 | 23.47 | 0.19 | 0.14 | 0.14 | 0.15 | 1.58 |
| CGH20CA | 30 | 4.65 | 12 | 44 | 32 | 6 | 36 | 52.5 | 74.9 | 6 | 12.45 | 5.5 | 8 | 3.7 | 4 | M5 x 6 | 20 | 20.55 | 9.5 | 8.5 | 6 | 60 | 20 | M5x19 | 27.1 | 36.68 | 0.37 | 0.28 | 0.28 | 0.25 | 2.48 |
| CGH20HA | 30 | 4.65 | 12 | 44 | 32 | 6 | 50 | 68.5 | 90.9 | 6 | 13.45 | 5.5 | 8 | 3.7 | 4 | M5 x 6 | 20 | 20.55 | 9.5 | 8.5 | 6 | 60 | 20 | 32.7 | 47.96 | 0.48 | 0.48 | 0.48 | 0.33 | 2.48 | |
| CGH25CA | 40 | 6.1 | 12.5 | 48 | 35 | 6.5 | 35 | 61 | 84 | 13 | 17.4 | 5 | 8 | 10 | 9.1 | M6 x 8 | 23 | 24.25 | 11 | 9 | 7 | 60 | 20 | M6x22 | 34.9 | 52.82 | 0.6 | 0.49 | 0.49 | 0.46 | 3.38 |
| CGH25HA | 40 | 6.1 | 12.5 | 48 | 35 | 6.5 | 50 | 78.4 | 101.4 | 13 | 18.6 | 5 | 8 | 10 | 9.1 | M6 x 8 | 23 | 24.25 | 11 | 9 | 7 | 60 | 20 | 42.2 | 69.07 | 0.74 | 0.73 | 0.73 | 0.59 | 3.38 | |
| CGH30CA | 45 | 7 | 16 | 60 | 40 | 10 | 40 | 69 | 97.4 | 13 | 19.75 | 8.7 | 9.5 | 9.7 | 9.7 | M8 x 10 | 28 | 28.35 | 14 | 12 | 9 | 80 | 20 | M8x25 | 48.5 | 71.87 | 0.95 | 0.7 | 0.7 | 0.71 | 5.1 |
| CGH30HA | 45 | 7 | 16 | 60 | 40 | 10 | 60 | 91.5 | 119.9 | 13 | 21 | 8.7 | 9.5 | 9.7 | 9.7 | M8 x 10 | 28 | 28.35 | 14 | 12 | 9 | 80 | 20 | 58.6 | 93.99 | 1.35 | 1.23 | 1.23 | 0.94 | 5.1 | |
| CGH35CA | 55 | 7.6 | 18 | 70 | 50 | 10 | 50 | 79 | 111.4 | 13 | 22.6 | 7 | 10.2 | 16 | 15.3 | M8 x 13 | 34 | 31.85 | 14 | 12 | 9 | 80 | 20 | M8x28 | 64.6 | 93.88 | 1.73 | 1.09 | 1.09 | 1.24 | 7.14 |
| CGH35HA | 55 | 7.6 | 18 | 70 | 50 | 10 | 72 | 103.4 | 135.8 | 13 | 23.8 | 7 | 10.2 | 16 | 15.3 | M8 x 13 | 34 | 31.85 | 14 | 12 | 9 | 80 | 20 | 77.9 | 122.77 | 2.46 | 2.02 | 2.02 | 1.62 | 7.14 | |
| CGH45CA | 70 | 9.7 | 20.5 | 86 | 60 | 13 | 60 | 97.2 | 137.6 | 13 | 23 | 8.7 | 16 | 18.5 | 18.5 | M10 x 17 | 45 | 39.85 | 20 | 17 | 14 | 105 | 22.5 | M12x37 | 103.8 | 146.71 | 3.56 | 2.35 | 2.35 | 2.38 | 11.51 |
| CGH45HA | 70 | 9.7 | 20.5 | 86 | 60 | 13 | 80 | 133.6 | 174 | 13 | 31.2 | 8.7 | 16 | 18.5 | 18.5 | M10 x 17 | 45 | 39.85 | 20 | 17 | 14 | 105 | 22.5 | 125.58 | 191.85 | 5.05 | 4.45 | 4.45 | 3.01 | 11.51 | |
Advantages:
1. High rigidity in reduced volume
Dense load-carrying structure provides strong support without increasing rail size.
2. Excellent resistance to deformation
Maintains straight-line accuracy under concentrated or localized loads.
3. Stable motion performance
Ensures consistent linear travel with minimal structural flex.
4. Efficient space utilization
Designed for installations where mounting space is limited.
5. Reliable long-term operation
Suitable for industrial environments requiring stable mechanical behavior.
Features:
1. Dense guiding structure design
2. High stiffness carriage configuration
3. Stable linear displacement
4. Optimized rail–block contact geometry
5. Designed for space-limited assemblies
Applications:
1. Compact industrial automation equipment
2. Precision mechanical assemblies
3. Linear positioning units
4. Industrial motion modules
5. Assembly machines with limited space
6. Mechanical support and guiding systems
