| Quantity: | |
|---|---|
GEG15ETL-2RS GEG17ETL-2RS GEG20ETL-2RS GEG25ETL-2RS GEG30ETL-2RS GEG35ETL-2RS GEG40ETL-2RS GEG45ETL-2RS GEG50ETL-2RS GEG60ETL-2RS GEG70ETL-2RS GEG80ETL-2RS GEG90ETL-2RS GEG100ETL-2RS GEG110ETL-2RS
ZGXSY, OEM, WORLD FAMOUS BRAND, NO BRAND
China
Steel, GCR 15, Bronze, PTFE composite, PTFE Fabric
GEG…ETL Series
12 Months / One Year
Earthmoving machinery joints Industrial press systems Heavy conveyor pivot units Structural support linkages
By International Express or Sea or Railway
1 PC
Description:
The GEG…ETL Series is a wide outer ring spherical plain bearing featuring a PTFE-based sliding liner for lubrication-free operation. The enlarged outer ring enhances housing support while improving load distribution across the bearing interface.
Designed for applications requiring high radial capacity and long service intervals, this series minimizes friction and eliminates periodic greasing. The composite liner ensures consistent motion performance even under fluctuating mechanical stress.
GEG…ETL bearings are particularly suitable for heavy industrial assemblies where structural strength and reduced maintenance are priorities.
Specification:
| Bearing number | Dimensions mm | Load ratings kN | Weight ≈kg | ||||||||
| d | D | B | C | dk | rs min | r1s min | α° ≈ | Dynamic | Static | ||
| GEG15ETL-2RS | 15 | 30 | 16 | 10 | 25 | 0.3 | 0.3 | 16 | 60 | 100 | 0.048 |
| GEG17ETL-2RS | 17 | 35 | 20 | 12 | 29 | 0.3 | 0.3 | 19 | 83 | 139 | 0.08 |
| GEG20ETL-2RS | 20 | 42 | 25 | 16 | 35.5 | 0.3 | 0.6 | 17 | 135 | 225 | 0.152 |
| GEG25ETL-2RS | 25 | 47 | 28 | 18 | 40.7 | 0.6 | 0.6 | 17 | 175 | 290 | 0.199 |
| GEG30ETL-2RS | 30 | 55 | 32 | 20 | 47 | 0.6 | 1 | 17 | 225 | 375 | 0.296 |
| GEG35ETL-2RS | 35 | 62 | 35 | 22 | 53 | 0.6 | 1 | 16 | 275 | 465 | 0.402 |
| GEG40ETL-2RS | 40 | 68 | 40 | 25 | 60 | 0.6 | 1 | 17 | 360 | 600 | 0.535 |
| GEG45ETL-2RS | 45 | 75 | 43 | 28 | 66 | 0.6 | 1 | 15 | 440 | 735 | 0.698 |
| GEG50ETL-2RS | 50 | 90 | 56 | 36 | 80 | 0.6 | 1 | 17 | 690 | 1150 | 1.42 |
| GEG60ETL-2RS | 60 | 105 | 63 | 40 | 92 | 1 | 1 | 17 | 880 | 1470 | 2.09 |
| GEG70ETL-2RS | 70 | 120 | 70 | 45 | 105 | 1 | 1 | 16 | 1130 | 1890 | 3.01 |
| GEG80ETL-2RS | 80 | 130 | 75 | 50 | 115 | 1 | 1 | 14 | 1380 | 2300 | 3.61 |
| GEG90ETL-2RS | 90 | 150 | 85 | 55 | 130 | 1 | 1 | 15 | 1710 | 2860 | 5.5 |
| GEG100ETL-2RS | 100 | 160 | 85 | 55 | 140 | 1 | 1 | 14 | 1840 | 3080 | 6.04 |
| GEG110ETL-2RS | 110 | 180 | 100 | 70 | 160 | 1 | 1 | 12 | 2680 | 4480 | 9.74 |
| GEG120XTL-2RS | 120 | 210 | 115 | 70 | 180 | 1 | 1 | 16 | 3020 | 5040 | 15.1 |
| GEG140XTL-2RS | 140 | 230 | 130 | 80 | 200 | 1 | 1 | 16 | 3840 | 6400 | 18.9 |
| GEG160XTL-2RS | 160 | 260 | 135 | 80 | 225 | 1.1 | 1.1 | 16 | 4320 | 7200 | 24.8 |
| GEG180XTL-2RS | 180 | 290 | 155 | 100 | 225 | 2.5 | 1.1 | 14 | 6000 | 10000 | 35.9 |
| GEG200XTL-2RS | 200 | 320 | 165 | 100 | 275 | 1.1 | 1.1 | 15 | 6600 | 11000 | 44.9 |
| GEG220XTL-2RS | 220 | 340 | 175 | 100 | 300 | 1.1 | 1.1 | 16 | 7200 | 12000 | 50.9 |
| GEG240XTL-2RS | 240 | 370 | 190 | 110 | 325 | 1.1 | 1.1 | 15 | 8580 | 14300 | 65.3 |
| GEG260XTL-2RS | 260 | 400 | 205 | 120 | 350 | 1.1 | 1.1 | 15 | 10000 | 16800 | 82 |
| GEG280XTL-2RS | 280 | 430 | 210 | 120 | 375 | 1.1 | 1.1 | 15 | 10800 | 18000 | 96.6 |
Advantages:
1. Lubrication-free service life
2. Enlarged outer ring stability
3. Reduced friction coefficient
4. Improved housing fit security
5. Lower operational noise
6. Extended replacement intervals
7. High radial strength performance
8. Reliable oscillation behavior
Features:
1. Wide outer ring configuration
2. PTFE composite sliding layer
3. Optimized radial force support
4. High-load structural design
5. Durable steel backing material
6. Surface-treated external ring
7. Designed for long-term articulation
Applications:
1. Earthmoving machinery joints
2. Industrial press systems
3. Heavy conveyor pivot units
4. Structural support linkages
5. Metallurgical equipment
6. Offshore mechanical assemblies
7. Energy sector installations
FAQ:
Q1: Are you factory or trading company?
A: We are factory with most competitive price and high quality.
Q2: Customized accepted?
A: Yes, sure. If that, please send us the drawing of the type with the picture will be most appreciated.
A3: Can I get some samples or more discounts?
A: Yes, just to contact us and we are honored to offer samples to you for checking.
Q4: How about the time of delivery ?
A: For the products in stock, it will be sent out in 1-3 days; Or it will be sent out 3-30 days according to the quantity.
Q5: What's your MOQ?
A: We can accept trial orders (even 1 pc) for prototype, there are plenty of stocks in factory, and can be shipped very fast.
Q6: How can I get a quotation?
A: Normally, we will quote within 24 hours. If you are in urgent, please give a call or let us know in your email with the details.
We need information bellow:
1.The Model Number/ the detail drawing of non-standard bearing;
2.Quantity;
3.Material;
4.Surface treatment;
5.Any special packing or other requirements.
Our Services:
Our Quality:
Quality is life. We use only the best quality materials to ensure that our product range meets the highest standards.
All products we sell are strictly selected and tested by our QC department.
Warranty:
We support a 12-month warranty for all products.
Payment:
We accept payment via TT (Bank transfer), PayPal, etc.
We accept bank transfers for large orders. For small orders, PayPal is preferred.
Shipping:
We offer as many shipping options as possible, including DHL, UPS, TNT, FedEx, EMS, air freight, and sea freight.
